MEBA Xtreme 800-510 – Semi-Automatic Bandsaw Machine

MEBA Xtreme 800-510 is a Semi-automatic straight cutting bandsaw up to 90°

MEBA high-performance package: electric ball screw saw feeding system with automatic cutting pressure- and feed control, saw blade lowers to the material in rapid speed
Hydraulic material full-stroke clamping
Powerful AC-saw drive for high efficiency coupled with low power consumption
Automatic adjustment of saw blade guidance to material width
Sturdy main clamping vice (double clamping vice)
67mm saw blade provides maximum cutting power
Minimum speed- and saw blade control on the bandwheel

Strongly built straight cutting bandsaw
Extremely rugged and powerful saw blade drive
Lowerable vice for a smooth and frictionless material handling
Sensitive saw feed automatic
Uses latest linear ball guideways to provide solit, smooth running and maintenance-free performance

90°	Ø 510 800×510
motor	14,5 kW
Saw blade [mm]	9000 x 67 x 1,6
Dimensions [mm] (length x width x height)	950 x 4250 x 2600
Material weight	max. 1000 kg/m
