MEP PH211-1 – Manual Pull-Down Bandsaw Machine

Machine Description

The PH 211-1 is a manual pull-down band sawing machine to cut metals mitering from 0° to +60°. Available with automatic downfeed (HB).

The PH211-1 is a manual pulldown bandsaw machine with one way mitring from 0-60° on the left. Featuring a capacity of 200mm x 150mm.

  • Sturdy cast iron structure
  • Electrical control board with 24v equipped with motor overload protection
  • Carbide blade guides instead of bearings to ensure better stability
  • Quick release lever for mitring
  • Saw head pivots with tapered bearings
  • Vice with quick release lever
  • Self-contained coolant system within the saw base with electric pump
  • Double spring for counter balance for head return
  • Swarf brush driven by blade
  • Measuring rod with scale for repeat cutting Instruction manual and spare parts list also supplied.

We also supply BAHCO BANDSAW BLADES and COOLANT for this machine.

Standard Features

Optional Features

  • HB Cutting Cycle
  • Hydraulic circuit with control valve for downfeed
  • 1.5 K200 Roller Table for Infeed and Outfeed
  • R1, R2  Measuring system with flip over stop
Cutting Capacity (mm) Round Square Rectangle
0° 180mm 180mm 200mm x150mm
45° 115mm 110mm 125mm x110mm
60° 70mm 70mm 70mm x 70mm
TECHNICAL DATA
Electric Motor Single Phase
0.75 KW
Electric Motor Three Phase
0.70/0.81 KW
Blade Size
2130mm x 20 x 0.9
Variable Blade Speed – Single Phase
N/A 80m/min
Variable Blade Speed – Three Phase
40/80 m/min
Machine Dimensions
1510mm x 645mm
Machine Weight
190Kg
PDF icon Download PDF
