MEP Shark 281 SXI EVO – Semi-Automatic Bandsaw Machine

Machine Description

The MEP Shark 281 SXI Evo is a semi-automatic, electrohydraulic bandsawing machine with one way mitring from 0°-60° on the left. Featuring a capacity of 280mm x 200mm.

  • Machine controls has the latest microprocessor designed by MEP
  • Control panel on an articulated arm
  • Low voltage soft keyboard
  • Diagnostic display & alarms
  • Self-contained hydraulic control unit, with high efficiency and low energy consumption
  • Two blade speeds 36/72m/min available with electronic inverter
  • Programmable head height control
  • Blade tensioning by electronic transducer with display
  • Steel base with removable coolant tank
  • Stock support roller
  • Swarf brush driven by blade
  • Measuring rod with scale for repeat cutting
  • Pre-set to be equipped with spray mist system

Standard Features

Optional Features

  • Vice pressure regulator
  • Electronic speed variator (inverter) 15-150 m/min
  • Supplementary foot pedal with emergency stop
  • Laser Projector & Work Light
  • Spray mist system
  • 1.5 K330 Roller Table for Infeed and Outfeed
  • R1, R2 and R3 Measuring system with flip over stop
Cutting Capacity (mm) Round Square Rectangle
0° 250mm 230mm 280mm x200mm
45° 190mm 180mm 180mm x 180mm
60° 120mm 110mm 110mm x 110mm
TECHNICAL DATA
Electric Motor Single Phase
N/A
Electric Motor Three Phase
1.5/1.8 KW
Blade Size
2950mm x 27 x 0.9
Variable Blade Speed – Single Phase
N/A
Variable Blade Speed – Three Phase
36/72 m/min
Machine Dimensions
2000mm x 1000mm
Machine Weight
435Kg
